Part Number
|
Reverse Stand-Off Voltage |
Breakdown Voltage VBR(V) |
Maximum Clamping Voltage |
Peak Pulse Current |
Certification |
Delivery Time |
||
|
Uni-Polar |
Bi-polar |
VRWM |
Min |
Max |
VC |
IPP(A) |
UL |
days |
|
5.0V |
6.40 |
7.00 |
9.2V |
163.0 |
√ |
7days |
||
|
6.0V |
6.67 |
7.37 |
10.3V |
145.7 |
√ |
7days |
||
|
6.5V |
7.22 |
7.98 |
11.2V |
134.0 |
√ |
7days |
||
|
7.0V |
7.78 |
8.60 |
12.0V |
125.0 |
√ |
7days |
||
|
7.5V |
8.33 |
9.21 |
12.9V |
116.3 |
√ |
7days |
||
|
8.0V |
8.89 |
9.83 |
13.6V |
110.3 |
√ |
7days |
||
|
8.5V |
9.44 |
10.40 |
14.4V |
104.2 |
√ |
7days |
||
|
9.0V |
10.0 |
11.10 |
15.4V |
97.4 |
√ |
7days |
||
|
10.0V |
11.1 |
12.3 |
17.0V |
88.3 |
√ |
7days |
||
|
11.0V |
12.2 |
13.5 |
18.2V |
82.5 |
√ |
7days |
||
|
12.0V |
13.3 |
14.7 |
19.9V |
75.4 |
√ |
7days |
||
|
13.0V |
14.4 |
15.9 |
21.5V |
69.8 |
√ |
7days |
||
|
14.0V |
15.6 |
17.2 |
23.2V |
64.7 |
√ |
7days |
||
|
15.0V |
16.7 |
18.5 |
24.4V |
61.5 |
√ |
7days |
||
|
16.0V |
17.8 |
19.7 |
26.0V |
57.7 |
√ |
7days |
||
|
17.0V |
18.9 |
20.9 |
27.6V |
54.4 |
√ |
7days |
||
|
18.0V |
20.0 |
22.1 |
29.2V |
51.4 |
√ |
7days |
||
|
20.0V |
22.2 |
24.5 |
32.4V |
46.3 |
√ |
7days |
||
|
22.0V |
24.4 |
26.9 |
35.5V |
42.3 |
√ |
7days |
||
|
24.0V |
26.7 |
29.5 |
38.9V |
38.6 |
√ |
7days |
||
|
26.0V |
28.9 |
31.9 |
42.1V |
35.7 |
√ |
7days |
||
|
28.0V |
31.1 |
34.4 |
45.4V |
33.1 |
√ |
7days |
||
|
30.0V |
33.3 |
36.8 |
48.4V |
31.0 |
√ |
7days |
||
|
33.0V |
36.7 |
40.6 |
53.3V |
28.2 |
√ |
7days |
||
|
36.0V |
40.0 |
44.2 |
58.1V |
25.9 |
√ |
7days |
||
|
40.0V |
44.4 |
49.1 |
64.5V |
23.3 |
√ |
7days |
||
|
43.0V |
47.8 |
52.8 |
69.4V |
21.7 |
√ |
7days |
||
|
45.0V |
50.0 |
55.3 |
72.7V |
20.6 |
√ |
7days |
||
|
48.0V |
53.3 |
58.9 |
77.4V |
19.4 |
√ |
7days |
||
|
51.0V |
56.7 |
62.7 |
82.4V |
18.2 |
√ |
7days |
||
|
54.0V |
60.0 |
66.3 |
87.1V |
17.3 |
√ |
7days |
||
|
58.0V |
64.4 |
71.2 |
93.6V |
16.1 |
√ |
7days |
||
|
60.0V |
66.7 |
73.7 |
96.8V |
15.5 |
√ |
7days |
||
|
64.0V |
71.1 |
78.6 |
103.0V |
14.6 |
√ |
7days |
||
|
70.0V |
77.8 |
86.0 |
113.0V |
13.3 |
√ |
7days |
||
|
75.0V |
83.3 |
92.1 |
121.0V |
12.4 |
√ |
7days |
||
|
78.0V |
86.7 |
95.8 |
126.0V |
11.9 |
√ |
7days |
||
|
85.0V |
94.4 |
104.0 |
137.0V |
11.0 |
√ |
7days |
||
|
90.0V |
100 |
111.0 |
146.0V |
10.3 |
√ |
7days |
||
|
100.0V |
111 |
123.0 |
162.0V |
9.3 |
√ |
7days |
||
|
110.0V |
122 |
135.0 |
177.0V |
8.5 |
√ |
7days |
||
|
120.0V |
133 |
147.0 |
193.0V |
7.8 |
√ |
7days |
||
|
130.0V |
144 |
159.0 |
209.0V |
7.2 |
√ |
7days |
||
|
150.0V |
167 |
185.0 |
243.0V |
6.2 |
√ |
7days |
||
|
160.0V |
178 |
197.0 |
259.0V |
5.8 |
√ |
7days |
||
|
170.0V |
189 |
209.0 |
275.0V |
5.5 |
√ |
7days |
||
|
180.0V |
201.0 |
222.0 |
292.0V |
5.1 |
√ |
7days |
||
|
190.0V |
211.0 |
233.0 |
308.0V |
4.8 |
√ |
7days |
||
|
200.0V |
224.0 |
247.0 |
324.0V |
4.6 |
√ |
7days |
||
|
210.0V |
237.0 |
263.0 |
340.0V |
4.4 |
√ |
7days |
||
|
220.0V |
246.0 |
272.0 |
356.0V |
4.2 |
√ |
7days |
||
|
250.0V |
279.0 |
309.0 |
405.0V |
3.7 |
√ |
7days |
||
|
300.0V |
335.0 |
371.0 |
486.0V |
3.1 |
√ |
7days |
||
|
350.0V |
391.0 |
432.0 |
567.0V |
2.6 |
√ |
7days |
||
|
400.0V |
447.0 |
494.0 |
648.0V |
2.3 |
√ |
7days |
||
|
440.0V |
492.0 |
543.0 |
713.0V |
2.1 |
√ |
7days |
||
